2000mm Pedestrian Barrier Panel
The 2000mm Interclamp Galvanised Pedestrian Barrier is a modular safety system designed to integrate fully with the Interclamp handrail system and provide rapid construction of pedestrian control structures. The galvanised barrier offers strength, durability and versatility enabling it to be used in a wide variety of applications. Panels can be shipped directly to site as a complete package by selecting the relevant stanchions for the installation.
Top and bottom rails are D48 size (48.3mm OD x 3.2mm wall) galvanised tube with 12mm diameter solid vertical bars. Following fabrication, the barriers are hot-dipped galvanised in accordance withAS/NZ4680 - 2006
Product Data & Dimensions
Size | Height (mm) | Width (mm) | Part No |
D48 | 1000 | 2000 | GI392D48/2000 |
Figures given as guidance only, dimensions and weights are subject to manufacturing tolerances and may be altered without prior notice.
Do not perform any pre-drilling, tube cutting, casting uprights or any other dimensionally critical processes prior to receiving fittings.
