  • Smooth, in-line handrail range
  • Compatible for use in conjunction with the standard Interclamp range.
  • Helps to meet compliance with AS 1428.1:2009 and other public access specifications
  • Internally expanding to suit 3.25mm wall tube or saddle-type assembly
  • Easy accommodation of slopes and access ramps
  • Powder coating available to suit AS 1318-1985 SSA Industrial Safety Colour Code

The Interclamp Assist range has been specially designed to help compliance with AS 1428.1-2009 Design for Access and Mobility and DDA public access requirements. In order to give our customers more choice, a range of both internally expanding clamps and saddle type fittings is available, neither of which requires the use of welding, threading or specialist tools. Our classic range of internally expanding fittings requires no riveting or drilling of tube, whereas the saddle-type fittings require less tube cutting and hence easier handrail alignment. No other special fittings are required, which enables full integration with both new Interclamp systems and the refurbishment or upgrading of existing tubular structures to help meet the newer access specifications.

In order to meet the requirements of the above standards, the range forms flush joints with size C42 tube. Tube (and fittings where necessary) may be coated in AS or RAL colours to help meet contrasting colour requirements, including the SSA Industrial Safety Colour Code, AS 1318-1985. Steps and disabled access slopes may easily be accommodated, facilitating compliance with public access standards.

For C42 size internally expanding Assist fittings (as with type 150), tubes must be 42.4mm od x 3.2mm wall thickness eg. 1 1/4” medium weight to AS 1074-1989. All cut tube ends must be deburred and treated with Interclamp Silver Galvanising Spray or other suitable protection. Optional O-rings may be fitted to each end of the expanding Assist fittings to achieve the best finish.
